Features
- LCD type touch panel
- Pneumatic ON/OFF Inking, Dampening & Impression
- Three main hard chromed cylinder
- Three Chain Delivery Gripper Bars
- Front Plate Loading system
- Single Lever Operating for Dampening, linking & Impression
- Vertical micro adjustment on plate cylinder
- Exhaust Fan for quick Drying
- Pre-set counter & digital speed indication
- Jogger system on delivery
- Centralized Oil Lubrication System
- Bearing type pull side lay with micro adjustment without stopping the machine
More Features
- Automatic Ink Cleaning Device
- Print with poly master & plates
- Double paper detector
- No Sheet Detector
- Askew paper detector
- Blanket jammed paper sensor
- Delivery table jammed paper sensor
- Delivery table auto-lowering device
- Delivery table lowest position sensor
- Spray powder device
- Anti-static equipment
- Speed Set Sliding type plate clamp
Technical Specification :
| Detail | KI-4-1622 | KI-4-1824 |
|---|---|---|
| Max.Size | 400x560mm | 450x620mm |
| Max.Printing Area | 375x550mm | 440x605mm |
| Min.size | 125x180mm | 125x180mm |
| Plate Size | 420x560mm | 480x620mm |
| Blanket Size | 460x570mm | 505x620mm |
| Paper Thickness | 30-300gsm | 30-300gsm |
| Ink Roller System | 14(3 form) Rollers | 14(3 form) Rollers |
| Water Roller System | 5(2 form) Rollers | 5(2 form) Rollers |
| Printing Speed Paper | 1000-8000 Sheet/Hour | 1000-7000 Sheet/Hour |
| Printing Speed N.W | 1000-3000 Sheet/Hour | 1000-3000 Sheet/Hour |
| Power Required | 4 kw Single Phase | 4 kw Single Phase |
| Machine Dimension | 4000 x 1100 x 1400 mm | 4500 x 1200 x 1500 mm |
| Approx Weight 2/3/4 | 1300/2000/2500 Kg. | 1400/2200/2800 Kg. |
